CX40M

CX40M Metallurgical Microscope

Professional Metallurgical Microscope

The Prism Optical Pro CX40M is a high quality upright metallurgical microscope ideal for high frequency and long session use. Optically superb, with reflected and transmitted illumination, and high-quality long working distance infinity plan achromat objectives, this is a professional instrument ideal for the demands of industry.

5 year warranty on defective parts and workmanship.

Specifications

Variant Transmitted & Reflected Reflected Transmitted
Viewing Head 30°inclined gemel trinocular head,
interpupillary distance: 54mm75mm,
diopter ±5 adjustable,
splitting ratio R:T=100:0 or 50:50
Eyepieces High eyepoint 10× 22mm with optional reticule,
High eyepoint 15× 16mm also available
Objectives Infinity colour corrected:
5× NA0.15 WD10.8mm,
10× NA 0.30 WD10mm,
20× NA0.45 WD4mm,
50× NA0.55 WD7.9mm,
100× NA0.80 WD2.1mm
Focus Coaxial focus adjust,
Coarse range: 28mm, fine precision: 0.002mm
Sample Height 28mm 28mm 78mm
Stage Double layer mechanical stage with X/Y coaxial adjustment,
size: 175mm×145mm,
moving range: 76mm×42mm.
Stage insert Glass plate Metal plate Glass Plate
Reflected illumination 5W LED, warm color. Koehler illuminator with oblique light device, center adjustable field and aperture diaphragm None
Transmitted illumination 5W LED, warm color None 5W LED, warm color
Condenser Type N.A.0.9 swing-out achromatic condenser with center adjustable aperture iris diaphragm.
Condenser fitted Yes No Yes
